Pressure: up to 16 bar
Temperature: up to +110 °C
Inner surface cleanliness: free from oil and solder residues
Tightness: 100% product testing
The products comply with EN 1254-1 and EN 1057 standards. Made of CW024A copper without internal coating. Designed for operation at temperatures up to +110 °C and pressures up to 16 bar. EPDM seals are used for water supply systems and HNBR for gas systems.
| Inlet diameter (mm) | Outlet 1 (mm) | Outlet 2 (mm) | Application |
| 9.52 (3/8") | 6.35 | 6.35 | Small residential multi-split systems |
| 12.7 (1/2") | 9.52 | 9.52 | Split systems with 2 indoor units |
| 15.88 (5/8") | 9.52 | 9.52 | R410A distribution |
| 19.05 (3/4") | 12.7 | 12.7 | Industrial VRF systems |
| 22.2 (7/8") | 15.88 | 15.88 | Multi-unit VRV systems |
